Description
Amplifiers for professional use fitted with strong front panels. With integrated 2-way crossover network and limiter. Very versatile due to high power reserves and silent cooling fans. A robust construction suitable for heavy duty usage: DJ’s, fixed installations and live performance.
- Output power: 8 Ohms 2x 800W (rms)
- Output power: 4 Ohms 2x 1200W (rms)
- Output power: Bridged 8 Ohms 2400W (rms)
- Frequency response: 10Hz – 20kHz (± 1.5dB)
- Input: XLR, 6.3mm jack
- Signal to noise ratio: >95dB
- Damping Factor: >500
- Slew Rate: 60V/uS
- Crosstalk: >105dB
- Input sensitivity: 775mV
- Input impedance: 20kOhm
- Connector: Binding posts & 4P Speakon
- Power supply: 220-240Vac, 50Hz
- Dimensions: 482 x 470 x 88mm (19″ x2U)
- Weight: 20.7kg
Blue LCD display for temperature, operating mode, power, protection and audio level
Signal, overload and bridge LED indicator on each channel
Automatic clip limiting and Ground lift function
Soft-start function
Innovative heatsink with temperature-controlled fans
Adjustable crossover network: 45-960 Hz / 450-9600 Hz
Switchable high-pass and low-pass filter
Suitable for 19″ rack mounting (2U)
Protected against short circuits, overload and heat
Stereo, parallel and bridge mode
High power output and excellent sound quality
